Clean Room Air Shower
Type: Personnel cleanroom air shower
Airflow arrangement: Single-side, double-side, three-side, surrounding or vertical options.
Nozzles: Stainless steel; diameter and quantity depend on the selected model.
Construction: Powder-coated steel or stainless steel.
Controls: Electronic control panel or PLC option.
Door interlock: Configuration confirmed to match the entry procedure.
Power supply: 220 V or 380 V, subject to model and destination.
Cleanroom Entry Configuration
Specify whether the chamber is for personnel, carts or materials, together with the maximum load and expected traffic per hour.
Confirm the internal chamber size, external footprint, door orientation and installation opening.
Select the required door interlock, cycle controls, sensor arrangement and emergency-stop function.
Brand LED electronic lighting is available, with a service life of more than 11 years, improved illumination and lower energy use.
CE certification documents are available for applicable configurations. Confirm the covered model and receive the relevant document with the order documentation.
Air Shower Selection Points
Compare nozzle arrangement and air velocity at the stated operating condition.
Review recirculation airflow, pre-filter and final-filter configuration.
Confirm adjustable cycle time and the expected entry procedure.
Check that the door-interlock logic matches personnel and material flow.
Plan access for filter replacement, fan service and routine cleaning.
Provide the room layout, available opening and electrical requirements.
Request final drawings, model-specific data and documentation before approving production.
Technology Parameters
| Model | Size | Air flow | Initial resistance | Rated power |
|---|---|---|---|---|
| Item | Single blow air shower for one person | Double blow air shower for one person | Double blow air shower for one person | |
| Model | ASG-1260/1 | ASG-1400/1 | ASG-1400/1.5 | |
| External size W x L x H (mm) | 1260x1000x2050 | 1400x1000x2180 | 1400x1500x2180 | |
| Internal size W x L x H (mm) | 790x930x1910 | 790x930x1910 | 790x1430x1910 | |
| Nozzle in stainless steel (pc) | 6.0 | 12.0 | 16.0 | |
| Nozzle air velocity (m/s) | ≥25 | ≥25 | ≥25 | |
| Noise at 1 m (dB) | ≤75 | ≤75 | ≤75 | |
| Fan | Power supply (V/Hz) | 380/50 | 380/50 | 380/50 |
| Power (W/set) | 750 x 1 | 600 x 1 | 750 x 1 | |
| Quantity /set | 2.0 | 4.0 | 6.0 | |
| Air flow (m3/h) | 1200.0 | 1500.0 | 2500.0 | |
| HEPA filter | Size W x H x D (mm) | 630 x 630 x 69 | 630 x 630 x 69 | 630 x 915 x 69 |
| Quantity (set) | 1.0 | 1.0 | 1.0 | |
| Pre-filter | Size W x H x D (mm) | 775 x 380 x 17 | 775 x 380 x 17 | 775 x 380 x 17 |
| Quantity (set) | 1.0 | 1.0 | 1.0 | |
| Total power supply/W | 780.0 | 630.0 | 780.0 |
| Brand Name: | Fete Filter | Product Category: | Air Shower |
|---|---|---|---|
| Place of Origin: | China | Condition: | New |
| Warranty Terms: | Confirmed for the selected model in the quotation | Custom Options: | Discuss dimensions and configuration with our team |
What information helps you quote this product?
Ans. Please send the application, required dimensions, quantity, destination and any drawing, existing label or site photo. We will use those details to check the requested configuration.
How is the delivery time confirmed?
Ans. Lead time depends on the final specification, quantity, documentation and production schedule. It is confirmed in the formal quotation after the configuration is reviewed.
What are your primary product offerings?
Ans. Fete Filter focuses on fan filter units, HEPA filters, pocket filters, other HVAC air filters, filter media, pass boxes and air showers for cleanroom and controlled-environment projects.
How can I get in touch with you?
Ans. You can use the contact page, email or WhatsApp links on this website. Include the product name and project details so the request can be routed correctly.
What are your payment terms?
Ans. Payment terms are confirmed in the formal quotation for the selected product, order value and destination.
Feel free to Ask questions
Plan your Clean Room Air Shower project with the right specs
Compare cleanroom air showers by chamber size, personnel capacity, door layout, nozzle arrangement, airflow, cycle controls, interlock and power.
Confirm chamber capacity, internal dimensions, door layout, airflow system, cycle controls and power supply before selecting this air shower.
Check these technical points
- Personnel capacity or maximum material load
- Internal chamber size, door layout and installation space
- Nozzle arrangement, airflow system and cycle controls
- Door interlock, power supply and cleanroom entry logic
Send these quote details
- Personnel per cycle or material dimensions and weight
- Room layout, door orientation and available opening
- Voltage, frequency, control and interlock requirements
- Quantity, destination and installation constraints
Selection guidance for Clean Room Air Shower
Confirm chamber capacity, internal dimensions, door layout, airflow system, cycle controls and power supply before selecting this air shower.
Compare nozzle arrangement, recirculation and filtration setup, interlock logic, construction and maintenance access with the site entry procedure.
Send personnel capacity or material dimensions, room layout, door orientation, voltage, controls, quantity and destination for review.
What buyers usually confirm before ordering
- Personnel capacity or maximum material load
- Internal chamber size, door layout and installation space
- Nozzle arrangement, airflow system and cycle controls
- Door interlock, power supply and cleanroom entry logic
